ShareEvaluator

ShareEvaluator is derived from Evaluator and is used to assign values to the cells calculated from a shared array (obtained via ArrayShare. Usually this calculation is done by means of a poly line function providing the “preference” values for the data in the array.

While the input array usually has a size of m_iNumCells, the output array has a size of (m+1)*m_iNumCells where m is the maximum number of neighbors of a cell.

In its raw form the element i*(m+1) + k is the value of the (k-1)-th neighbor of cell i (for k > 1), whereas the element i*(m+1) is the value of the cell itself..

Often, however, the output data is used to make weighted random numbers so within a cells “subarray” we accumulate the numbers:

../../images/SingleEvalCumulate.png

A raw subarray and its cumulation.

Given a subarray

\((s_i)_{0 \leq i \leq i+1}\),

where

\(s_i = outputarray[k \cdot m + i]\),

with \(m\) being the maximum number of integers, and \(k\) an integer,

the cumulated array is

\((c_i)_{0 \leq i \leq i+1}\)

where

\(c_0 = s_0\), and \(c_i = s_i + c_{i-1}\) for \(i > 0\)

Code:
ShareEvaluator.h
ShareEvaluator.cpp

Attributes

ATTR_SHAREEVAL_NAME

ShareEvaluator”

action name

ATTR_SHAREEVAL_ARRAYNAME

ShareEvaluator_%s_arrayname”

template for array name

ATTR_SHAREEVAL_POLYNAME

ShareEvaluator_%s_polyname”

template for poly name

The attribute names of the array and the PolyLine in the input files must have the form “ShareEvaluator_<id>_arrayname” and “ShareEvaluator_<id>_polyname”, respectively, where <id> is an arbitrary string (which must be passed to the constructor.

Public Methods

constructor

ShareEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, bool bCumulate, intset &sTriggerIDs);
ShareEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, bool bCumulate, int iTriggerID);
pPop

A pointer to the SPopulation object performing this action.

pCG

A pointer to the SCellGrid object on which the simulation runs.

sID

An ID for this action (used to construct the names of the shared array and the poly line) .

adOutputWeights

Array to hold the output weights. The size of this array is (m+1)*NumCells, where m is the maximum number of neighbors of a cell.

adInputData

Array containing the input data with size equal to the number of cells (often one of the environment arrays).

bCumulate

Already cumulate the values for every cell in the output array.

iTriggerID

ID of event which should trigger a recalculation (for an altitude evaluator everything stays the same until a new geography is loaded. when the avaluation has to be redone).

sTriggerIDs

A set if event IDs which should trigger to a recalculation.

destructor

virtual ~SingleEvaluator();

The destructor deletes the PolyLine object if one has been created.

preLoop

virtual int preLoop();

Creates the array name and tries to get it from ArrayShare.

initialize

virtual int initialize(float fT);

Recalculates the output data if required.

finalize

virtual int finalize(float fT);

Reset the update flags.

extractAttributesQDF

virtual int extractAttributesQDF(hid_t hSpeciesGroup);

Creates the attribute names for the poly line and the shared array and reads the array name and the poly name, then tries to read and construct the poly line.

writeAttributesQDF

virtual int writeAttributesQDF(hid_t hSpeciesGroup);

Creates the attributes names for the poly line and the shared array and writes them, then writes the poly line to file.

tryGetAttributes

virtual int tryGetAttributes(const ModuleComplex *pMC);
pMC

A ModuleComplex object.

Creates the attribute names for the poly line and the shared array and reads the array name and the poly name from the``ModuleComplex`` object, then tries to read and construct the poly line.

setOutputWeights

void setOutputWeights(double *adOutput);
adOutput

An array containing values destined for output.

The variable m_adOutputWeights is set to a pointer to the previously filled array adOutput.

notify

void notify(Observable *pObs, int iEvent, const void *pData);
pObs

The observable which sends the event.

iEvent

ID of the event.

pData

Pointer to data pertaining to the event. It must be cast to the correct type.

(implementation of the Observer interface)
If the event is equal to one of the event IDS in the trigger set, the update flag is set.

isEqual

virtual bool isEqual(Action<T> *pAction, bool bStrict);
..`pAction``

Pointer to an action object to compare with this.

bStrict

Strictness of comparisons (ignored here).

pAction is equal to this, if it is a ShareEvaluator and their ID’s match.

showAttributes

void showAttributes();

Displays the poly line data.

Protected Methods

void calcValues();

The elements at position iCellIndex*(m_iMaxNeighbors+1) are set to the poly line evaluation of m_adInput[iCellIndex] if there is aa poly line. Otherwise it is set to m_adInput[iCellINdex].

constructor

void exchangeAndCumulate();

The “free” positions in the output array (those corresponding to the neighbors) are set to the evaluation values of the neighbors.

If cumulation is required this is done here.
