MultiEvaluator

MultiEvaluator is derived from Evaluator and is used to combine the output arrays of Evaluator objects in various ways. Before being combined the values are multiplied by a weight which is read from the input data.

../../images/MultiEvaluatorCombinations.png

Possible combinations:

MODE_ADD_SIMPLE

0

Addition of the ouput values

MODE_ADD_BLOCK

1

Blocked addition of the output values

MODE_MUL_SIMPLE

2

Multiply output values

MODE_MAX_SIMPLE

3

Maximum of the output values

MODE_MAX_BLOCK

4

Blocked maximum of the output values

MODE_MIN_SIMPLE

5

Minimum of the output values

Blocked addition: only do addition for elements where none of the corresponding Evaluators’ output array is 0. Blocked maximum: only do maximum for elements where none of the corresponding Evaluators’ output array is 0.

Note: Generally the Evaluators used in a MultiEvaluator shoud not be cumulated.

Code:
MultiEvaluator.h
MultiEvaluator.cpp

Attributes

ATTR_MULTEVAL_NAME

“MultiEvaluator”

action name

Type Definitions

typedef std::vector<std::pair<std::string, Evaluator<T>*> > evaluatorinfos;

An evaluatorinfo is a list of pairs of evaluator weight names and Evaluators. The weight names are used to get the values of the weights from the input file.

Public Methods

constructor

MultiEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, evaluatorinfos &mEvaluators, int iMode, bool bDeleteEvaluators);
pPop

A pointer to the SPopulation object performing this action.

pCG

A pointer to the SCellGrid object on which the simulation runs.

sID

An ID for this action.

adOutputWeights

Array to hold the output weights. The size of this array is (m+1)*NumCells, where m is the maximum number of neighbors of a cell.

mEvaluators

The list of Evaluators and weight names to use.

iMode

The combination mode (one of the MODE_XXX_XXX above).

bDeleteEvaluators

If true the Evaluator objects will be deleted.

destructor

virtual ~MultiEvaluator();

Deletes some internal arrays and, if required, the Evaluator objects.

preLoop

virtual int preLoop();

Calls the preLoop() method of all Evaluator objects.

postLoop

virtual int postLoop();

Calls the postLoop() method of all Evaluator objects.

initialize

virtual int initialize(float fT);

Calls the combination method corresponding to th required mode.

finalize

virtual int finalize(float fT);

Calls the finalize() method for all Evaluator objects and resets the update flag.

extractAttributesQDF

virtual int extractAttributesQDF(hid_t hSpeciesGroup);
hSpeciesGroup

HDF handle for the species group to read from.

Reads the weight values and the attributes for all Evaluator objects from the specified group of a QDF file.

writeAttributesQDF

virtual int writeAttributesQDF(hid_t hSpeciesGroup);
hSpeciesGroup

HDF handle for the species group to write to.

Writes the weight values and the attributes for all Evaluator objects to the specified group of a QDF file.

tryGetAttributes

virtual int tryGetAttributes(const ModuleComplex *pMC);
pMC

A ModuleComplex object.

Gets the weight values and the attributes for all Evaluator objects from the module complex.

Example of a MultiEvaluator entry in a population XML file

<module name="MultiEvaluator" id="Alt+NPP" >
    <param  name="Multi_weight_alt" value="0.2" />
    <param  name="Multi_weight_npp" value="0.8" />
    <module name="SingleEvaluator" id="Alt" >
        <param  name="AltPref" value="-0.1 0 0.1 0.01 1500 1.0 2000 1 3000 -9999" />
    </module>
    <module name="SingleEvaluator" id="NPP" >
         <param  name="NPPPref" value="0.0 0.0 1.2 1.0" />
    </module>
</module>

setOutputWeights

void setOutputWeights(double *adOutput);
adOutput

An array containing values destined for output.

The variable m_adOutputWeights is set to a point to the previously filled array adOutput.

notify

void notify(Observable *pObs, int iEvent, const void *pData);
pObs

The observable which sends the event.

iEvent

ID of the event.

pData

Pointer to data pertaining to the event. It must be cast to the correct type.

(implementation of the Observer interface)
If the event tyoe is EVENT_ID_FLUSH, the update flag is set, if any of the Evaluator objects’ update flag is set.

isEqual

virtual bool isEqual(Action<T> *pAction, bool bStrict);
pAction

Pointer to an action object to compare with this.

bStrict

Strictness of comparisons (ignored here).

pAction is equal to this, if it is a MultiEvaluator and all the corresponding `` Evaluator`` objects are equal and the weight names and weight values match.
