SingleEvaluator

SingleEvaluator is derived from Evaluator and is used to assign values to the cells calculated from an environment array. Usually this calculation is done by means of a poly line function providing the “preference” values for the environment data.

While the input array usually has a size of m_iNumCells, the output array has a size of (m+1)*m_iNumCells where m is the maximum number of neighbors of a cell.

In its raw form the element i*(m+1) + k is the value of the (k-1)-th neighbor of cell i (for k > 1), whereas the element i*(m+1) is the value of the cell itself..

Often, however, the output data is used to make weighted random numbers so within a cell’s “subarray” we accumulate the numbers:

../../images/SingleEvalCumulate.png

A raw subarray and its cumulation.

Given a subarray

\((s_i)_{0 \leq i \leq i+1}\),

where

\(s_i = outputarray[k \cdot m + i]\),

with \(m\) being the maximum number of neighbors, and \(k\) an integer,

the cumulated array is

\((c_i)_{0 \leq i \leq i+1}\)

where

\(c_0 = s_0\), and \(c_i = s_i + c_{i-1}\) for \(i > 0\)

../../images/SingleEvalPart.png

The environment values (e.g. altitude) of a cell are copied to an array, to which a poly line function is applied. The results are cumulated for potential use by an other action, e.g. WeightedMove.

Code:
SingleEvaluator.h
SingleEvaluator.cpp

Attributes

ATTR_SINGLE_EVAL_NAME

“SingleEvaluator”

action name

(constructor parameter)

(user defined)

name of poly line
(user defined): This is the name of an attribute in the QDF holding values for a PolyLine object.
(constructor parameter): the name is passed to the constructor as the parameter``sPLParamName``.

Public Methods

constructor

SingleEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, double *adInputData, const char *sPLParName, bool bCumulate, intset &sTriggerIDs);
SingleEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, double *adInputData, const char *sPLParName, bool bCumulate, int iTriggerID);
SingleEvaluator(SPopulation<T> *pPop, SCellGrid *pCG, std::string sID, double *adOutputWeights, const char *pInputArrayName, const char *sPLParName, bool bCumulate, intset &sTriggerIDs);
pPop

A pointer to the SPopulation object performing this action.

pCG

A pointer to the SCellGrid object on which the simulation runs.

sID

An ID for this action.

adOutputWeights

Array to hold the output weights. The size of this array is (m+1)*NumCells, where m is the maximum number of neighbors of a cell.

adInputData

Array containing the input data with size equal to the number of cells (often one of the environment arrays).

pInputArrayName

Name of an input array (which wll be obtained by means of an ArrayShare` object).

sPLParName

Name of an attribute holding the data for a PolyLine function. This name can e the empty string if no poly line is needed-

bCumulate

Already cumulate the values for every cell in the output array.

iTriggerID

ID of event which should trigger a recalculation (for an altitude evaluator everything stays the same until a new geography is loaded, at which point the evaluation has to be redone).

sTriggerIDs

A set if event IDs which should trigger to a recalculation.

destructor

virtual ~SingleEvaluator();

The destructor does nothing.

initialize

virtual int initialize(float fT);
fT

Simulation time step.

If the input data array is NULL, an attempt is made to obtain the array from ArrayShare with the name of passed in the sInputArayName parameter of the constructor. Then, if an update is needed, the values are recalculated.

finalize

virtual int finalize(float fT);

Reset the update flags.

extractAttributesQDF

virtual int extractAttributesQDF(hid_t hSpeciesGroup);
hSpeciesGroup

HDF handle for the species group to read from.

Obtains a PolyLine object by extracting the attribute with the name in m_sPLParName.

writeAttributesQDF

int writeAttributesQDF(hid_t hSpeciesGroup);
hSpeciesGroup

HDF handle for the species group to write to.

Writes the PolyLine data as an attribute with the name in m_sPLParName.

tryGetAttributes

virtual int tryGetAttributes(const ModuleComplex *pMC);
pMC

A ModuleComplex object.

Gets a PolyLine object with the name in m_sPLParName from the module complex.

setOutputWeights

void setOutputWeights(double *adOutput);
adOutput

An array containing values destined for output.

The variable m_adOutputWeights is set to a pointer to the previously filled array adOutput.

notify

void notify(Observable *pObs, int iEvent, const void *pData);
pObs

The observable which sends the event.

iEvent

ID of the event.

pData

Pointer to data pertaining to the event. It must be cast to the correct type.

(implementation of the Observer interface)
If the event is equal to one of the event IDS in the trigger set, the update flagis set.

isEqual

virtual bool isEqual(Action<T> *pAction, bool bStrict);
..`pAction``

Pointer to an action object to compare with this.

bStrict

Strictness of comparisons (ignored here).

pAction is equal to this, if it is a SingleEvaluator and the names of the PolyLine match.

showAttributes

void showAttributes();

Displays the poly line data.

Protected Methods

calcValues

void calcValues();

The elements at position iCellIndex*(m_iMaxNeighbors+1) are set to the poly line evaluation of m_adInput[iCellIndex] if there is aa poly line. Otherwise it is set to m_adInput[iCellINdex].

exchangeAndCumulate

void exchangeAndCumulate();

The “free” positions in the output array (those corresponding to the neighbors) are set to the evaluation values of the neighbors.

If cumulation is required this is done here.
